| RX-V665 | ||
|---|---|---|
| Amplifier Section | Kanaler | 7.1-channel |
| Dynamic Power per Channel (8/6/4/2 ohms) | -/100/110/125 W | |
| Surround Sound Processing | DSP Programs | 17 (with CINEMA DSP 3D mode) |
| Dialogue Lift | Yes | |
| SILENT CINEMA / Virtual CINEMA DSP | Yes | |
| Dolby TrueHD | Yes | |
| Dolby Digital Plus | Yes | |
| DTS-HD Master Audio | Yes | |
| Dolby Digital | Yes | |
| DTS-ES Discrete 6.1, DTS 96/24 | Yes | |
| Adaptive DSP Level | Yes | |
| Audio Features | Pure Direct | Yes (incl. Bitstream) |
| Compressed Music Enhancer | Yes | |
| YPAO sound optimization | Yes | |
| Adaptive DRC (Dynamic Range Control) | Yes | |
| Initial Volume & Maximum Volume Setting | Yes | |
| Bi-amp capability | Yes | |
| Audio Delay | Yes (0-240 ms) | |
| 192kHz/24-bit DACs for all channels | Yes (Burr-Brown) | |
| Digital ToP-ART / High Current Amplification | Yes | |
| Video Features | 1080p-kompatibel HDMI | Yes |
| Deep Color (30/36 Bit) | Yes | |
| x.v.Color | Yes | |
| Opdateringshastigheder på 100/120Hz og 1080p/24Hz | Yes | |
| Auto Lip-Sync kompensation | Yes | |
| Opskalering af analog til HDMI | Yes | |
| Fuld opkonvertering af analog video til HDMI | Yes (up to 720p analog input) | |
| Connectivity | HDMI indgange/udgange | 4 / 1 |
| Front AV Input | Mini Jack | |
| Phono-indgang | Yes | |
| Component Video Input/Output | 2 / 1 | |
| S-video ind-/udgange | 1 / 0 | |
| Multi-Channel Input | 8ch | |
| Preout | F/C/Sr/Sb/Sw | |
| Extensive Connection | iPod-kompatibilitet via Yamaha Universal Dock | Yes |
| Bluetooth Compatibility via Bluetoothﾂｮ Wireless Audio Receiver | Yes | |
| Mini-jack indgang på frontpanel | Yes | |
| Digitale lydindgange (optisk/koaksial) | 4 (2 / 2) | |
| Tuner Section | FM/AM tuner | Yes |
| User Interface | On-screen display | Yes |
| SCENE | Yes | |
| Fjernbetjening | Learning/Preset | |
| Zone Control | Zone 2- lydudgang | Yes |
| +12 Trigger udgange | Yes | |
| Fjernbetjeningsindgange (IR) | Yes | |
| General | Mål (B x H x D) | 435 x 151 x 364 mm |
| Vægt | 8.5 kg | |
| Audio Technical Specifications | Total Harmonic Distortion | 0.06% |
| Signal/støj forhold | 100 dB | |
