| HTiB |
| Kanaler |
5.1 channel system |
| Systemets totale udeffekt |
625W |
| Receiver |
Max. udgangseffekt |
105 W x 5 (4 ohms, 1 kHz, 0.7% THD For Europe) |
| Minimum RMS Output Power |
100 W x 5 (6 ohms, 1 kHz, 0.9% THD) |
| Dynamisk udeffekt/kanal (8/6/4/2 ohms) |
105/130/150 W (6/4/2 ohms) |
| SCENE |
Yes |
| Mini-jack indgang på frontpanel |
Yes |
| YPAO Sound Optimiｚation |
Yes |
| Compressed Music Enhancer |
Yes |
| HDMI Input / Output |
2 / 1 |
| Digitale lydindgange (optisk/koaksial) |
3 (2 / 1) |
| 192 kHz/24-Bit D/A-konvertere |
Yes (All channels) |
| Surround Programs |
8 |
| Total Harmonic Distortion |
0.06% (1 kHz, 50 W/6 ohms) |
| Signal-to-Noise Ratio (250 mV) |
100 dB |
| Mål (B x H x D) |
435 x 151 x 318 mm |
| Vægt |
8 kg |
| Højttalersystem |
Systemfrekvensrespons |
28 Hz–40 kHz |
| Front højttaler |
Type |
Acoustic suspension |
| Drivers |
6.5cm cone full-range driver |
| Input Power (Nominal / Max) |
30 W / 80 W |
| Følsomhed |
81 dB/2.83 V/1 m |
| Mål (B x H x D) |
90 x 90 x 109 mm |
| Vægt |
0.45 kg./unit |
| Centerhøjttaler |
Type |
Acoustic suspension |
| Drivers |
6.5cm cone full-range driver |
| Input Power (Nominal / Max) |
30 W / 80 W |
| Følsomhed |
81 dB/2.83 V/1 m |
| Mål (B x H x D) |
90 x 90 x 109 mm |
| Vægt |
0.45 kg./unit |
| Surround Speaker |
Type |
Acoustic suspension |
| Drivers |
6.5cm cone full-range driver |
| Input Power (Nominal / Max) |
30 W / 80 W |
| Følsomhed |
81 dB/2.83 V/1 m |
| Mål (B x H x D) |
90 x 90 x 109 mm |
| Vægt |
0.45 kg./unit |
| Subwoofere |
Type |
Advanced YST |
| Udgangseffekt |
100 W |
| Driver |
16cm cone |
| Mål (B x H x D) |
262 x 264 x 316 mm |
| Vægt |
6.9 kg |
