| AV Receiver |
| Amplifier Section |
Kanaler |
9.2 |
| Surround Sound Processing |
CINEMA DSP |
Yes（HD3） |
| DSP Programs |
23 |
| Virtual Presence Speaker |
Yes |
| Dialogue Lift |
Yes |
| SILENT CINEMA / Virtual CINEMA DSP |
Yes |
| Dolby TrueHD |
Yes |
| Dolby Digital Plus |
Yes |
| Dolby Pro Logic IIx |
Yes |
| DTS-HD Master Audio |
Yes |
| Audio Features |
Pure Direct |
Yes |
| Compressed Music Enhancer |
Yes |
| YPAO multi-point measurement |
Yes with RSC (Reflected Sound Control) and Angle measurement |
| Adaptive DRC (Dynamic Range Control) |
Yes |
| Initial Volume & Maximum Volume Setting |
Yes |
| A.R.T. Wedge |
Yes |
| Bi-amp capability |
Yes |
| Audio Delay |
Yes (0-250 ms) |
| 192kHz/24-bit DACs for all channels |
Yes (Burr-Brown) |
| Video Features |
HDMI 3D passthrough |
Yes |
| HDMI Audio Return Channel |
Yes |
| Component upconversion |
Yes |
| HDMI upscaling |
Yes (Analog to HDMI / HDMI to HDMI) |
| Video adjustment |
Yes with variable parameters |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync |
Yes |
| Connectivity |
HDMI indgange/udgange |
8 (front 1) / 2 (Simultaneous) |
| HDMI CEC |
Yes (SCENE, Device control) |
| USB Input |
iPod/iPhone, USB Memory, Portable Audio Player |
| Network Port |
Napster / vTuner Internet Radio |
| Dock Port |
1 (YDS-12, YID-W10) |
| Front AV Input |
HDMI/USB/Analog Audio/Optical/Composite/S video |
| Digital Audio Input/Output: Optical |
4 (front 1) / 1 |
| Digital Audio Input/Output: Coaxial |
3 / 0 |
| Analog Audio Input/Output |
10 (front 1) / 1 |
| Phono-indgang |
Yes |
| Component Video Input/Output |
4 / 1 |
| S-video ind-/udgange |
5 (front 1) / 1 |
| Composite Video Input/Output |
5 (front 1) / 1 |
| Multi-Channel Input |
8ch |
| Preout |
11.2ch |
| Headphone Output |
1 |
| Tuner Section |
FM/AM tuner |
Yes |
| User Interface |
On-screen display |
Graphical User Interface |
| SCENE |
SCENE PLUS (12 sets) |
| App Control |
Yes |
| Web Browser Control |
Yes |
| Fjernbetjening |
Yes (Preset, Learning, Macro, LED Back Light) |
| Subwoofer fjernbetjening |
YES |
| Zone Control |
Zone 2- lydudgang |
Preout |
| Zone 3-lydudgang |
Preout |
| Zone 4-lydudgang |
Optical Output |
| Powered Zone |
Zone 2/3/4 |
| Zone Video Output |
Component/S/Composite |
| Zone GUI |
Yes |
| RS-232C Interface |
1 |
| +12 Trigger udgange |
2 |
| Fjernbetjeningsindgange (IR) |
2 / 2 |
| Party Mode |
Yes |
| General |
Standby Power Consumption (IR only) |
0.3 W |
| Mål (B x H x D) |
435 x 192 x 467 mm |
| Vægt |
19.9 kg |
